Commercial Automatic Coffee Grinder with Touch Screen Gind by weight. 74mm Burr (Flat wheel)

Core Specifications

• Burr Type: Flat burrs

• Burr Material: High-quality hardened stainless steel (often available with optional Titanium coating for longevity)

• Burr Diameter: 64 mm

• Motor Power: 350 Watts

• Voltage: 220V/50Hz or 110V/60Hz (depending on region)

• Rotation Speed: ~1400 RPM (at 50Hz) or ~1600 RPM (at 60Hz)

• Grinding Capacity: Approx. 2.5 - 3.0 grams per second (espresso setting)

• Hopper Capacity: 1.2 kg (approx. 2.6 lbs)

Key Features

• On-Demand Grinding: Features an electronic dosing system that allows you to program timed doses for single, double, and triple shots.

• Control Panel: Large, high-resolution LCD touchscreen for easy adjustment of dose times and menu navigation.

• Adjustment System: Stepless micrometer adjustment, allowing for precise control over the grind size.

• Portafilter Holder: Hands-free adjustable cradle that fits most standard commercial portafilters.

• Build Quality: Heavy-duty die-cast aluminum body for stability and heat dissipation.

• Safety Features: Overload protection and an safety switch on the bean hopper.

Physical Dimensions

• Width: Approx. 190 mm

• Depth: Approx. 300 mm

• Height: Approx. 560 mm (with hopper attached)

• Net Weight: Approx. 11.5 kg (25.3 lbs)

Summary:

The JX-680P is often seen as a budget-friendly alternative to the Mazzer Super Jolly Electronic or similar 64mm flat-burr grinders. It is known for its quiet operation and the intuitive touchscreen interface which simplifies the workflow in a busy cafe environment.
